Warning: These product may represent a possible electrical shock and/or fire hazard if improperly installed or attached in any way. Products should be installed in accordance with these instructions and with all current electrical codes and/or the current National Electric Code (NEC).
IMPORTANT: TO AVOID ELECTRIC SHOCK, DISCONNECT POWER PRIOR TO INSTALLATION!
Caution: Injury to person(s), damage to the fixture, and/or mounting surface may result if the fixture is pulled from the surface improperly. To reduce the likelihood of such injury / damage, mount on a surface that is mechanically and structurally sound.
Use only a mild soap and/or water with soft cloth to clean the fixture as harsh chemicals will damage the light fixture. Do not wipe the fixture with a rough cloth as it may scratch the fixture and/or lens.

Installation Method: Direct Wire

A single fixture or the first fixture in a lighting run is attached directly to the house wiring.

1. Remove the lens cover from the fixture by lifting its back edge up gently and rotating it towards the front of the fixture. See Figure 1.
2. Punch out whichever knockout is best suited for connection to the 120V supply wires. Knockouts are located along the back and top of the housing. See Figure 2.
3. Detach the cover of the wiring compartment by rotating the plastic screws. See Figure 3.
4. Install cable clamp and connect fixture wires following the National Electric Code and local building requirements. See Figure 4. AC supply wires to fixture lead-wires: Black to Black, White to White, Green / Bare Wire to Yellow / Green (Ground) inside the fixture. Secure each connection using the quick connector provided on the fixture lead wire. See Figure 5.
5. Tighten the 2 captive screws to secure the fixture to the desired mounting surface.
6. Replace the wiring compartment cover, securing the lip under the metal retaining tabs. See Figure 6.

ADDITIONAL NOTES:

• If your system has no ground wire, you should consult a qualified electrical technician before proceeding with the installation.
• Electric shock, overheating, low or no light output and/or shorten fixture life can result if proper grounding is not done.
• Be sure that the wires are not pinched or damaged by any part of the housing or cover.

Installation Method: Plug-In

A single fixture or the first fixture in a lighting run plugged into a nearby power outlet via power cord.
NOTE: Power cords are sold separately from the fixtures. (must be added on)

1. Remove the lens cover from the fixture by lifting its back edge up gently and rotating it towards the front of the fixture. See Figure 1.
2. Determine the desired mounting location for the fixture.
3. Tighten the 2 captive screws to secure the fixture to the mounting surface.
4. Replace the lens cover by tucking the front lip under the front edge and pressing down firmly along its entire length until secure. See Figure 9.
5. Insert the power cord into the INPUT end of the fixture.
6. Plug the 3 prong grounded plug into a 120V outlet receptacle.

Mounting the Fixture

1. Determine the desired mounting location of the fixture and mark the location of the mounting holes (mark at the small end of each hole).
2. Tighten the 2 captive screws to secure fixture to mounting surface.
3. Replace the lens cover by tucking the front lip under the front edge and pressing down firmly along its entire length until secure. See Figure 7.

Connecting Multiple Fixtures Together

Plug ends of the end-to-end connector or interconnect linker wires into OUT power connection ports on adjacent fixtures. Fixture and connector ends are marked IN and OUT respectively; Be sure to route power in and out according to these markings. Up to 50 fixtures can be connected in series.

Additional Safety Measures

1. Do not look directly at LED light source
2. Do not touch the LED diodes.
3. To avoid electrical shock, do not turn on fixture(s) with missing or damaged lens(es).
4. There are no serviceable parts inside the LED module; Do not attempt to repair the unit.
5. The power cord and extension jumper cables are not serviceable. Inspect periodically and replace if damage is detected.
6. RISK OF FIRE: Keep fixtures away from curtains and other combustible materials.
7. Suitable for indoor, dry locations only.
8. This product is suitable for use in dimmable circuits. For best results (full range dimming), use a Lutron DV600P, DVCL-153P, DVEL-300P type dimmer switch.
